The Nor'easter Rises June 2nd, 2017
A southerly wind rolled in, ten miles from head to tail. It skipped across the heather and cotton-grass high upon the moorland. Then twisting, downwards toward the valley and through the tall pines, shaking pine needles to the forest floor as it went.
Driven forth with a burning hunger, it pushed on towards the lights of the town. Gathering strength with each dive and swoop, the wind danced across the thatch rooftops, circling eastwards towards the coast. As it ran along the roof of the assembly rooms, the rusty weathervane creaked and slowly spun around to a new heading.
The wind crossed the eastern farms until it met the old windmill on the hilltop, causing the ancient wooden blades to groan as they began to turn. The scent of prey carried up from the farmlands, and the wind circled one more for the kill.
It's been hard since ol' Fessler died. I reckon he knew more about tar than any man alive. He said he'd teach me it all, in time. I think he'd always hoped his son would take over from him, but they fell out and he moved west. I think he became a stage player or such.
So Fessler took me on as a prentice in his stead. He used to teach me all sorts; not just building the kilns, that was easy enough, but the caulking, woodcarving, even metalworking from time to time. I guess you could say I'm a jack of all trades 'round these parts.
It was never easy for him, what with his leg. He'd taken a good hit during the Great Storm of '63, and he'd always found it hard getting around since then. He used to say he could feel his bones creaking each time the Nor'easter blew through, like it was letting him know who's boss.
I spent my whole first summer rebuilding the tar kilns up on the eastern hilltops, just me and Fessler. There's a whole bunch of ways to make a good kiln, but we used to dig them into the hillside itself and build a simple frame around it. The heat from the fire would draw the resin out of the wood and we'd drip it down into a barrel underneath. There's more to making tar than folks think. It's not just burning wood. In fact, if you let it burn you'll mess up the whole thing and get nothing out. Did that a couple of times back in those first weeks. You need to keep a good layer of peat on top to keep the air out.
It took a long time for me to get comfortable with being exposed up there on those hills. Most folks don't go up there; they say because of the smell from the burning tar, and I'll give 'em that I suppose, although I grew to like the aroma myself. You can catch a hint of it from miles away sometimes when the breeze carries it. I reckon they're just scared of being away from the town though. Up there, there's nothing much to protect you when the wind whips through. I asked Fessler once, what he'd do if the windchimes rang while he was up there--he just laughed and said he'd let the wind take him.
Still, I learned a lot about tar from him. You got your birch tar, you got your peat tar, even coal tar. I heard up in the North Wilds it comes right up out of the ground, though I ain't never seen anything like that myself. Here on the east coast though, we got pines, and lots of 'em.
You can do a lot with pine tar. It ain't as hot as you'd think, you can work it at room temperature. You can use it as a glue, or for weatherproofing. You can spread it all over cloth and get a good oilskin out of it, and you'd be thankful for that when it starts raining a pissbucket down in the spring. You can even seal a boat hull with it, though I ain't stupid enough to mess with boating. I heard too many tales.
Mostly though, I make it for sealant.
That's what I was doing, that first evening in the fall when the wind changed. I was warming up a pot on the stove so I could go fix the Bridgers' window while there was still a sliver of day remaining. You gotta heat it a little to apply it right. I was just about to mix in some linseed oil to help it soak when the shop door swung open. Sampson came dashing in, all out of breath.
"Wind's coming!" he shouted. "Glanville's gonna set up in the stable!"
I nodded. There wasn't much time. The workshop wasn't weatherproof; it couldn't be really, what with needing the furnaces open for air. Normally I'd have preferred to be down by the river, where the valley keeps the wind off. You can hold up pretty good down there with only minimal sealant around the window frames. And Jethro Wilkins would probably be there too so we'd get to have a right laugh while we waited. But it was too far and there wouldn't be much time. The stable would have to do, and my tar would have to wait.
I moved the pot off the heat--last thing I need would be my workshop to burn down too--and grabbed my emergency bag from by the door. I could already feel the breeze picking up as I stepped out into the square. It was here. I could see Sampson running down the street knocking on as many doors as he could. I hoped he'd get everyone safe before the wind came.
I reached the stable to see Mayor Glanville pulling people inside. "Come on!" he yelled. "Get in!"
The bell on the assembly hall was ringing by now. We shuffled into the safety of the stable. There must have been at least ten of us crammed in there, though the horses didn't seem to mind. It was just an old wooden framed building but the sealant was all new. I knew because I'd done it myself that summer. People around these parts appreciate the value of quality sealant. With enough pine tar around the gaps you could keep any wind out, even the Nor'easter.
Sampson was last in, along with the Bridger family. I watched as Glanville pulled down the heavy wooden bar to lock the door.
We sat in silence for what seemed like a year. Nobody wanted to say anything. You could hear the wind outside, growing louder with every minute. I wiped the tar from my hands onto my apron. Finally Weaver spoke up.
"What the hell's it doing here this early? It's not even harvest yet."
"It's come early before," said John Bridger. "When my Tim was a kid it woke in November once."
"Bah, November!" shouted Weaver. "It's September! The Nor'easter's never come in September before."
"Maybe it's not the Nor'easter?" I ventured. "Maybe it's a different wind?"
"Like hell it is!" shouted Marson. "The Nor'easter's the only wind in these parts, everyone knows that!"
"I'm just sayin'..."
"Well if your gonna say somethin' then say somethin' that makes sense! Ain't no point telling stories and getting folks all worried."
We sat as the gale outside roared. There was nothing we could do now, it might take till light for the storm to pass. John Bridger paced the room, pausing to studying the brick fireplace set into the far wall.
"Couldn't we at least get a fire started?" asked John Bridger. "It's as cold as a winters' day in here."
"Use the brain your mother gave you, John," muttered Marson. "You'd just open up that chimney damper wouldn't you, and let the wind whistle right down the flue and get in here."
John sat back down dejectedly, but we all knew Marson was right. Even a modest air gap could be a danger; an open hatch was like an invitation.
"What if it is a different wind?" asked John Bridger. "I mean it came up real quick... What if it's stronger than the Nor'easter?"
"What are you sayin'?" asked Weaver?
"Nothing." He paused. "Well yeah, OK, I'll say it. What if it is stronger? What if it gets in?"
"It won't get in," I said.
"But what if it does? I mean it's only a wooden frame sealed with tar, it could crack it open somewhere and..."
"It won't."
"And this is new weatherproofing here, it's not been tested and what with Fessler gone it--"
"Now there ain't nothing wrong with my sealant John Bridger," I said, pointing my finger at him. "I make quality sealant, as good as you'll find in--"
Glanville stood up and motioned to everyone. "Now let's everyone just calm down a little." He stepped between me and John and adjusted his waistcoat. "No-one's questioning your caulking Cal."
Seemed to me like they were. But I let it go. Glanville had a way of taking charge of a room.
"Now I've been mayor here for ten winters now and I know how to handle the Nor'easter. It's been early before, and this'll be no different. There'll be plenty of sheep still out on the eastern farms. There was no time to bring them inside. It'll take one of those, then it'll go back to sleep."
"Horseradish," said Weaver. "It'll take two sheep at least. If it's woken this early it must be hungry."
"It'll take one, just like usual," Glanville said. "Mark my words, it just needs a meal and it'll be back to sleep."
And that, it seemed, was that. We settled down on the straw until dawn. I managed a few hours sleep at least, despite the cold.
Come the morning, we left our shelter and went back to work. I spoke to old farmer Danson later that day when he came into town. It took four sheep that first night. They found the bones scattered all the way up to Wenwright's mill, the flesh stripped clean off them.
The farmers called a meeting on the Sunday evening. As we filed into the assembly hall I recognized most of the faces; I'd done work for pretty much all the farms round these parts over the past year or so. The torchlight faded away into the corners, leaving just silhouettes of heads. I pushed my way around to the side of the crowd, where I could get a good view of the stage.
Glanville sat up there at the table, alongside the Town Clerk and Tom Farthingsworth. Those two looked uneasy at the size of the crowd, but Glanville managed to keep that smile he always had.
"Alright, settle down folks. Settle down," said Glanville. "I've asked Mr Farthingsworth here to go over..."
He was cut off by someone in the crowd, I couldn't see who. "It's been taking more sheep!" the voice cried.
"It took one more of mine last night!" That was Mr. Danson. He had the largest farm around here, over near Bridgewater.
"OK now folks," Glanville said as he tried to manage the mob. "One at a time."
Weaver took the floor. "Now something ain't right here. Everyone knows it. The Nor'easter is never this busy this time of year. And it's never taken this many before, we've lost eight sheep in a week. Most years we'd lose no more than ten through a whole season--"
"This isn't the Nor'easter!" shouted Tendale, cutting him off. "This is a southerly wind!"
"No it ain't," said Weaver dismissively.
"It sure as hell is. I've seen which way the weathervanes go, it's come down from the mountains."
Glanville stepped forward. "The Nor'easter claims these lands. No other wind would try and stake a claim here."
"I'm just sayin' what I know," continued Tendale. "This wind came from the south. This ain't the Nor'easter."
"What are you going to do about it?" shouted someone.
I could see it in Glanville's eyes; that slight glimmer of uncertainty. He always put up that smiling facade, but if you knew him you could spot it peeling away.
Then a new voice came from the back. It was Wenwright, the mill owner. "We should send for the aeromancer."
That caused a murmur through the crowd.
"What aeromancer?" asked someone.
"The aeromancer, the one who lives up in Dryton. I saw him once when I was a boy. He'll know what to do."
"Dryton? That's fifty miles away."
"Folks, please," said Glanville. "Now folks, we don't need to send for no aeromancer. That ain't gonna be cheap, and the town's already losing money each time this wind comes through. It don't make no sense for us to be paying a small fortune just to have someone come down here and tell us what we already know. Now Mr Farthingsworth here has taken care of our bells and chimes for nigh-on thirty years."
That was certainly true enough. Farthingsworth kept the warning bells in good order, and went up on the roofs to repair the weathervanes every season no matter the weather. He'd seen as much wind come through this town as anyone. A sound of agreement rippled across the crowd.
"Now Tom, why don't you explain things to these kind folks here."
Farthingsworth lifted himself out of his chair and addressed the crowd. "Well, we'll start by bringing the herds in early. It'll mean we'll need more hands hired to keep them fed once they're indoors, but Mr. Barson here has agreed to provision a one-off stipend to cover the season."
The farmers grumbled a little, but I could see they were thinking it over. Farthingsworth looked around the room, and seeing no disagreement he continued on:
"Then we'll take a herd of goats west across the moors, and stake them up on the northwest brow. Once this wind realizes there's no food around here, it'll go for those instead."
I spoke up. "And what about when those are gone?"
"If we place the goats to lead it northwards, well then it'll probably follow the valley north up the coast. There's plenty of wild deer there. We can encourage it to move on to where there's better takings."
"Just where are you gonna get these goats from?" asked Tendale.
"Well perhaps Mr Danson could... "
"Me?" asked Danson. "I'm relying on my animals for the winter. I need every last one of them, I can't afford to keep losing them each time a new wind decides it wants a nice lunch."
"I'm sure under the circumstance the town council could perhaps reimburse you...?" he looked to Glanville for assurance.
"Yes," Glanville said. "I believe we can accommodate that." That gleaming smile came back to life. "Well then gentlemen, I think that's settled."
So settled it was, though it seemed to me that not everyone agreed. I heard old Wenwright again from the back:
"I still think we should send for..." he began, but his voice was drowned out by the talk of the crowd. Once Glanville had an idea set it was hard to have it otherwise with him, and so the hall slowly began to empty out.
Three nights later it came again, just as the sun set. I was coming home from resealing the roof on the Jenner house, over by the coopers' yard. I'd noticed the breeze picking up but I figured it only for a passing zephyr. It built quickly though, quicker than I'd ever seen before. I hurried down the narrow alley, my footsteps accompanied by the tinkle of the windbells that hung from every gutter. Only when I heard the thundering peal of the windchimes from the belltower did I drop my bucket and run for it. As the alley opened up onto the square, I finally caught sight of the lights of the inn and made like hell for it.
The windchimes only struck when high winds were coming. You could hear them for miles, with the deep, dull tone from the 30ft tubes. The heaviest one weighed nigh-on 400 pounds. It's a sound you don't forget in a hurry.
They were closing up the door as I got there. It was busy, maybe a hundred people all crammed inside. The inn was a good, safe building to be in. Big thick timbers that wouldn't give even if a howling gale hammered at them. Folks were standing around near the doorway.
"What happened?" asked Will Fenkins. "Didn't they put the goats out like we planned?"
"They put them out alright, went up there Monday," I answered. "Guess it didn't count for much."
People milled around without much to do. I saw Mary Colson, the butcher's wife, looking panicked.
"Billy?" she called. "Billy, where are you?"
Billy was her son, just turned twelve last month. Good lad, bit absent minded though. I looked around but couldn't see him.
The wind was here in full force now, bringing fierce rain with it. The drops tapped a fast rhythm against the window glass. I heard a commotion and turned back around to see Mary struggling at the door.
She was trying to lift the heavy draw bar that held the door shut. Jack Porter grabbed her hand and tried to pull her away.
"What the hell are you doing Mary?" he shouted.
"My Billy! He's still out there!"
"Mary," shouted Jack as he wrestled with her. "Mary, listen. You can't go out there. It's here!"
She didn't listen. "But he's still out there!" she cried. The windchimes rang out again.
I peered out the window, trying to spot any signs of life in the darkness. A flash of lightning lit the square, and a movement caught my eye.
"Look!" I cried. "Over by the well."
The crowd pushed to the window, trying to get a view. There was almost no light to see by now, but there was definitely the outline of a figure, curled up in a ball beside the steps to the well.
"Let me out!" Mary shouted. "Let me go!"
Jack let out a sigh. "Alright, wait. You stay here, I'll get him. I'll get him."
Ferris and I lifted the heavy wooden bar off the door, and the rumble of thunder filled the room. I caught Jack's eye. He didn't say anything, but his eyes spoke for him.
"Please, please hurry!" begged Mary.
Jack leaned to me and whispered. "You shut this door behind me the moment I get out there," he said. I nodded.
We opened the door and Jack dashed out. The wind pushed hard at it, but between the two of us we got it closed again and dropped the bar back in place. We all hurried to the window and watched anxiously as Jack sprinted across the square, shielding his face from the rain. The dull atonal sound of the windchimes struck again, drowning out the noise of the storm.
As he reached the well he heaved the Colson kid up over his shoulder. A giant rumbling roar filled the air, like an almighty bear. It was too late; the wind had seen them. It seemed like maybe he was going to make it back, but as he ran a gust hit him and knocked him backwards off his feet. The kid tumbled over and landed face down on the cobblestone.
Jack scrambled up again and grabbed the kid's hand, but the wind surged again and lifted the kid up into the air. Jack held on and shouted something, I couldn't hear what. But it didn't matter. The wind ripped little Billy Colson right out of his hand and took him away into the night.
We had the door open ready as Jack came back into the inn, and got him a seat once he was safely inside. I'll never forget that look in his eyes. There was nothing he could say, he just sat there dripping wet with his mouth open. Nobody knew what to say. Someone pushed a shot of whiskey into his hands but he just held it.
He looked up into the eyes of Mary Colson. "I'm sorry Mary," was all he could offer.
She burst into tears, and collapsed into a chair.
I'd never seen the assembly hall so full, we must have had half the town in there. They had to stall the meeting for an another half hour as more people were still arriving in off the north high road, some from as far up as Woodhole I heard.
At half-noon they got started. Glanville was first to speak up.
"Alright folks, we all know why we're here. Let's try and keep this in order. Who's first?"
Sampson took the floor. "This thing's out to kill us. It doesn't just want a taste of mutton, it wants blood. It's found what it likes and it wants more."
"What are you saying we should do about it?" asked one of the Wiversham brothers.
"What can we do about it?" cried someone.
"One at a time, please folks," said Glanville. "Now we always managed alright with the Nor'easter, so I think--"
"The Nor'easter never took people before!" shouted Sampson, cutting him off. "We always made sure to get everyone inside and it was happy enough with just the sheep."
"Darn thing took one of my cows last year," said Farmer Hoggis.
"Okay, sure, from time-to-time. But never people." Sampson turned to address the whole crowd. "Which of us is going to be next?"
"Hear hear!" the crowd bellowed.
"I say we do like Wenwright said," he continued. "We send for the aeromancer, we pay him what he wants, and we do it soon before it takes another."
The hall door opened again as still more people poured in, I couldn't see who.
Tendale stood forward and took the floor. "This new wind is trying to claim this land for itself," he said. "I say we head up to Forcastle while we still can; there's good land there and we could--"
"This is our home. I grew up here." The anger in the voice surprised me, especially when I realized it was mine. "Wh-- well now we've had Wintersmith's in these parts for going on a hundred years now. I'm not going to be driven out of my home. Now I agree with Mr. Sampson here, we need to send..."
I didn't get to finish. The crowd was beginning to part, and a strange old man pushed his way to the front. He was dressed like nothing I'd ever seen before, a mass of blue satin cloth and white beard which held up a tall staff, or the staff held up him, I couldn't be sure which. He walked slowly forwards into the light, and the attention of the whole room seemed to draw around him.
"Who are you?" Glanville asked.
"My name is Petrel," the old man said, "and you sent for me did you not? I am an aeromancer."
A murmur rippled across the crowded hall. Glanville exchanged a blank look with the other councilmen, his mouth open in a rare loss for words.
"I'm not sure that--"
"I sent word for him," said someone. It was Wenwright.
"You, Sam Wenwright?" gasped Glanville. "Without the approval of the council, you just went and sent for him on your own authority?"
"And well he should have!" snapped Petrel. "I am glad to hear someone in here has one ounce of sense in their head!"
He stood at the front of the crowd and turned to address them. Every time he moved, the various charms and tools that hung off his staff fluttered to and fro. He waved his staff in anger with each fiery word.
"You foolish men!" he cried. "You'd try to control the winds, would you? What did you think you could achieve?"
"We uh..." started Sampson, "We thought we could lead it away from here, up to the north w--"
"You thought you'd lead it, did you, hmm?" Petrel asked. "Oh, such naivety. You would control something you do not understand? This is no seasonal wind, this is a wild hunter. It has exhausted the food in the mountains and now it wants to feed here. It will not go, it will not leave, until it has exhausted the supply here too. And now you've given it a taste of human flesh, and it knows there's plenty more where that came from."
"So what do we do?" Mayor Glanville asked. "How can we kill it?"
"Ha!" exclaimed Petrel. "You can't kill a wind, not the likes of you anyway. No, this wind has upset the balance. The cycle must be restored. Only the might of the Nor'easter can fight a thing this strong. We must let it fight for its territory."
A ripple of excitement ran over the crowd. Sampson spoke:
"It could be another three months before the Nor'easter wakes. How many more would it take before then?"
"Matters must be brought forward then. We must venture to sea." Petrel eyed the murmuring crowd as he spoke, watching to see if they would accept what he would say next. "We sail far to the north-east, where the cold air meets the warm ocean. We sail right into the heart of the storm and we wake it. We wake the Nor'easter."
I couldn't believe what I was hearing, and nor could anyone else. The crowd erupted with noise.
"Are you crazy?"
"That's insane!"
Glanville stepped in front and managed to get the crowd calmed down a little, then turned back to talk to the aeromancer.
"What are you saying here?" he asked. "You're just going to waltz on over into the middle of the ocean, and poke this thing with a stick until it wakes up? You're crazy. You're gonna get eaten alive. It's impossible."
"Impossible? You have a boat, do you not?"
"Well sure we do, sure. But we only use them in the spring, before the summer westerlies arrive. To venture to sea--in this season--is dangerous. The seas are as open as the skies, there's no shelter out there. And you're not just talking about rowing, you'd be going further out than anyone's ever done before. What if there's a leak? If something goes wrong way out there, you've no chance of getting back to shore in time."
"And you would have a better thought, hmm?"
He did not. No-one said anything.
"Who would be sailing this boat? You?"
"I would go myself, yes," replied Petrel.
Marson had been sitting on a box at the side of the room, watching the proceedings quietly. He smoked on his old pipe, as he often did when he was thinking. He took it from his mouth and spoke:
"Takes two men to crew a sailing skiff," he said. "Can't do it on your lonesome. Who else are you going to find stupid enough to go along with you? You couldn't get me out on those waters with this new wind on the loose, not for any money."
"Speaking of money," interrupted Glanville, "if we were to hire you to go out there..."
Petrel gave a small sniff, and said "I would ask only four hundred for my services."
"Four hundred!" cried Glanville. "Extortion!"
I pulled Glanville aside and quietly said: "It may be the only way to get this thing fixed."
He wasn't pleased with the idea. "I don't see why we need to..."
"And you'd live with it, for another 3 months would you?" That was Weaver. He spoke loudly and drew the full attention from the room. "You ain't seen what these things do. It ain't quick, or pleasant. I seen how the Nor'easter et a cow once, when I was a lad. I sat in the lake hut and watched it circle around all night as it finished it off. It doesn't kill you straight away. It holds you in the air for hours, slowly grinding away at your skin, scraping you raw with sand until there's nothing left on you but bones. You could hear that poor cow up there in the sky, moaning in agony, all the way through till morning. So, Mr. Glanville, you can wait, if you like. But I say we go with yonder wizard here, before it comes for us too."
The crowd stood in silence. I wanted to say something, but I couldn't find the words. It seemed our choices were shrinking by the minute.
"How exactly do you wake a wind?" asked Wenwright.
"The secrets of aeromancy are passed from master to apprentice, given not to you. But I shall need a barrel of pine tar, and help to apply it."
I wasn't sure I liked where this was going at all.
Of course they talked me into going. More fool me, but Glanville persuaded me into it like he always does. Said the aeromancer needs pine tar for his work, and I was the best person to help with it. And of course, on such a long journey the boat might need fixing or resealing, or the ropes need retarring, so it fell down to me to be the one to go with him. Normally I'd just wait for the summer boats to row back into shore to patch them up, but not this time. One of us had to go to sea.
We loaded the skiff with our provisions early that morning. The jetty bustled with life as everything was brought aboard. The aeromancer had bought several boxes with him, containing all sorts of strange equipment. Everyone had turned out to see us off, or perhaps just to see what all the fuss was about. Petrel certainly drew a crowd, looking like some kind of ancient jester and behaving no better. I'd made sure to wear my best oilskin, and packed a good lunch of cheese and pork sausage, as well as enough salted beef in case of delay. Marson carried the small barrel of pine tar aboard and stowed it amongst Petrel's equipment, while I checked over everything a second time.
Mayor Glanville stood on the wooden jetty, talking with a small group of onlookers. I climbed back out of the boat and walked down the jetty to him, the boards creaking with every step, and pulled him aside.
"Are you sure about this, Glanville?" I asked quietly.
"I need someone aboard I can trust, Cal. He'd only agree to payment up-front. There's a lot of the town's money about to get on that boat and just sail right off over the horizon. Now I need you to keep a watchful eye on him; make sure he does the right thing by us."
I glanced back at the aeromancer. He stood alone on the skiff, messing with some kind of odd cloth contraption he was folding away into his cloak. He seemed to not notice all the activity around the dock, caring more for the strange items he carried with him. I watched as he held up his staff; from its end there protruded some strange arrangement of small cups fixed on an axle, which gently spun as the air moved past them.
"I trust him," I said.
With the boat fully loaded, Marson leaned against a mooring post and lit his pipe.
"More fool ye. It ain't the money I'm worried about," he said as he shook the match out. "What if this aeromancer is wrong? What if we wake the Nor'easter, and now we have two winds to deal with?"
Marson said it loud enough for Petrel to hear, and while he paused briefly he said nothing in reply. Perhaps the thought worried him, but he ignored it and continued checking his equipment.
It seemed like we were ready. I made my excuses and climbed into the boat. Marson lifted my pack off the jetty and threw it down to me. Petrel was checking his strange spinning staff again. He measured the length of string that hung from it, and seeming to reach some kind of conclusion, he spoke:
"A breeze is rising," he said. "It is time."
And with that, we left. The crowd waved us off, and I managed a wave back, before pushing the boat off from the jetty.
On the dock, Marson and Glanville watched us depart. Glanville waved happily, Marson just sat on a bollard and stared while he took a drag on his pipe.
"You'll never see 'em again," he said to Glanville.
"Cal's with him. He's a good lad, he'll see us right."
I watched them become dots in the distance as I rowed us further away from shore. Petrel paid no attention to me, and just stood at the bow, looking out to sea.
"Could Marson be right?" I asked him as I pulled the oars toward me. "About ending up with two winds to deal with?"
Petrel paused, and took out a pipe of his own.
"Perhaps," he said. "The future is not always clear, only the present is."
Aeromancers moved in cryptic ways, it seemed. I decided it was best to let it be, and carried on rowing.
The morning sun shone brightly across the sea and glinted off the ocean waves. I wasn't used to this. I'd been in a boat before, sure, but usually just to fix it. The mainland was getting awfully far away from us.
A gentle breeze had been following us from the shore, slowly building. I pulled the oars in and went to set up the sail instead. With a small skiff like this, you could either row it or sail it. Seeing as we could be going a long way, I thought it best to let someone else do the work.
Petrel had bought several strange boxes with him, and I almost tripped over them while trying to get the sail unfurled.
"Dammit!" I cursed. "What's in all these boxes anyway, Petrel?"
"Many things, Cal. Many things," he replied. "And all of which we shall need! Speaking of which..."
He stood up and picked up the box he'd been sitting on. He opened it up, and from within took out a strange device of stick and cloth and handed it to me. While I examined it in puzzlement, he reached back into the box and pulled out a small cage, containing an even smaller baby rabbit.
"Aha!" he exclaimed as he looked in at the rabbit. "Yes my little fellow, you'll do nicely."
"It's a rabbit," I said.
"It is."
"Why do you have a rabbit?"
"To gain a favorable breeze, of course. Here my lad, hold the kite up."
I held up the cloth device, the "kite" he'd called it, while he took the rabbit's cage and tied a string from the kite onto it. The rabbit looked on helplessly as Petrel let the cage dangle down from the kite.
"Now," he said, "you hold this string tight while I launch it."
I did as he asked, and with a slight horror I realized the fate of this poor rabbit. He took hold of the kite and held it high in the air, then as the breeze caught it he pushed it higher and released it. The kite shot high up into the sky, and tugged hard at the string.
"There we are!" he said. "Now release it!"
I let go, and the kite was ripped straight from my fingers. It whirled away up into the sky, with the poor caged rabbit dragged below it. I couldn't help feel a little sorry for it. It wasn't a strong breeze, but it'd strip that rabbit down to the bone with no trouble.
"You're feeding the breeze?" I asked.
"Of course. We'll need a good push behind us to get where we need to go. A small offering will keep the breeze chasing us."
"Is that wise though? I mean to be feeding it like that? What if it comes back for us? Like with the goats..."
"It's only a passing zephyr, it can't hurt us. No sense being afraid of nature. The gentle zephyrs don't cause no harm to anyone, 'cept maybe to take a duckling or chick from time to time. It's all part of the great cycle."
The great cycle. Fessler used to talk about that a lot. Some folks get scared of the small breezes, but they never bothered Fessler. The trees need the breezes to carry their seeds, he said, and we need the trees to make shelter. Can't have one without the other.
It worked, anyway. The wind picked up, and we gathered speed. The skiff sailed onwards to sea, its sail billowing. I wondered if perhaps we were safe from a wind that would carry us with it, much as a dog could not bite its own collar. The thought brought me no comfort.
"You're not scared of the wind at all, are you?" I asked him.
"Scared?" replied Petrel. "Oh, I'm scared enough, I suppose, as when you stand near a high cliff edge and see the waves far below, and you worry what would happen if you accidentally fell over."
He looked out across the vast ocean, watching the waves move past us.
"But I don't fear it. You'll learn that as you age, young Cal. When I was your age, I used to think I was invincible. When you get a little older, you start to think about death a lot. It starts to haunt you, starts to follow you wherever you go. But eventually you accept the balance of the world, and when you're as old as me you no longer worry about how you'll die. If the wind takes me, then it takes me. If not, then I shall live for another day. But I won't hide, not from nature anyway. One day I'll finally go, I suppose, and fulfill my role in the cycle."
I left him to his thoughts. There was plenty to do, anyway. The ropes on the skiff hadn't been tarred since the summer. You gotta apply it twice a year at least, or the water will get in there and rot it. I took my brush and started on the forestay.
"You haven't said how you plan to wake this thing," I said. "Do you even have a plan?"
"Of course I have a plan! Impertinence!"
"Well," I continued, "why haven't you told it yet?"
"And give away all my secrets?" replied Petrel. "I may be old but I'm no fool. That Glanville cares only for money. If I told him how to do everything himself, he would have no need of me! No, the knowledge of an aeromancer is best kept to those who can make best use of it."
"And to those who can get paid for it? That's a pretty little fortune you've got yourself there."
"I have to eat, like any man."
"You'll be eating for a good long while with all that."
He smiled with a sigh, then took out his pipe and started filling it.
"My work is not like yours, young Cal. We can not all spend our days making tar and sealing window frames. I spend my life in study. Perhaps I may not be needed for years, but when I am needed, I must be ready."
"Still... four hundred buys a lot of studying."
"Aye."
"So what is the plan then? I assume you can tell me now that we're way out here?"
He pointed the end of his pipe at the bundle of cloth that sat boxed behind me.
"There it is."
I wiped the tar clean from my hands, then poked the box suspiciously.
"What is it?"
He seemed amused by my ignorance. "That," he said with a grin, "is a balloon."
"A what?" I looked back up at him as he continued:
"A balloon. I ignite the tar below to fill it with hot air, and it will rise into the sky."
"Then what?"
"Then the smell from the burning tar will wake the Nor'easter."
He asked me to tar the balloon, so I set to work. He'd explained to me that he wanted the whole thing to catch light once it got high enough, so I unfolded it out a piece at a time, and gave it a good coating. There wasn't much room to work on the little skiff, and I almost fell overboard a couple of times. I was slightly nervous about the idea of lighting any kind of fire on this boat--with all the tar around it'd be real easy for the whole thing to go up like a light, us included. I decided not to mention it to Petrel, hoping he knew what he was doing.
"Have you ever done this before?" I asked as I worked.
"No."
"So how do you know it'll work?"
"I read about it, once. In an ancient book. A book is what we aero--"
"I know what a book is. I'm not stupid. And you think just because someone wrote it down in a book means that it'll work?"
"Perhaps."
"Perhaps? That's all you ever say! I'd feel a lot happier about all this if you were sure about anything!"
"One cannot live ones life in absolute certainty. I must deal with the facts I have at hand."
"Isn't there some way we could just kill it?"
"That's not our place."
"Our place?"
"We all have a place in the great cycle. The winds move around us, above us, and we are beholden to them. It is not for us to rule above all, but to maintain balance in the world."
"Well I got news for you, aeromancer, this thing's going to kill us if we don't kill it first."
"And you would rule the skies would you, young Cal? You would decide what lives and dies?"
Petrel stood looking to the horizon.
"No. We restore the balance. We let the cycle mend itself. These lands belong to the Nor'easter. It forms part of the cycle, like all things, and must be balanced if the cycle is to continue."
"I'm really not sure I follow you at all."
He turned and smiled.
"Bless you, child. Would it matter if a leaf understood how it is blown on the wind? Us two are carried forward on this journey together, and we will go where the cycle takes us, no matter if we understand why. Our futures lie in the hands of powers beyond our reckoning."
The sun was high in the sky now. I'd lost sight of land hours ago. I'd never heard of anyone being this far out to sea before. The fishing boats never dared to venture too far away from the shore.
"So... you're saying you don't actually know if this is going to work?"
"Know? I do not deal in knowing the future, nor the past. All I see is the present. Your land was out of balance, and so I will attempt to level that balance. What fate decides past that is not for us to choose."
We sailed onwards. Far on the horizon, clouds were forming.
The sky was a dark grey now. Clouds circled high above, and I could feel the breeze coming at me sideways. In front of us a great storm rotated slowly, with small gaps of sunlight breaking through.
"We can't do this," I said. "We can't go in there."
"Have no fear, Cal. The Nor'easter sleeps."
"We could still turn back," I said.
"Be strong! We must push forward!"
He grabbed the line and steered us towards the storm, his eyes fixed on it like a madman. It was getting hard to hear over the ever-increasing wind.
"We must breach the eyewall and sail to the Eye of the storm!"
He trimmed the sail to keep a good reach, and plunged ahead towards the storm. We were caught in the cyclone now; the wind was blowing straight sideways and strong waves kept pushing at our boat. Drops of water pelted my face, and I couldn't tell whether it was rain coming down or spray coming up.
A giant wave picked us up and sent us crashing down again. I sat at the stern, trying to balance the weight, and tried to keep hold of the thwart to stop myself getting thrown out. Petrel paid no attention to me, he just kept holding the lines with his eyes fixed on the our goal.
I closed my eyes and thought of being on land, but it only made me feel sicker. As wave after wave tossed our boat around, I could hold my stomach no longer and let go over the side. The spray was relentless; I would wipe the water from my brow only for it to come straight back.
It felt like hours, but the waves began to calm, and the wind had dropped. We were right in the middle. I looked up and could see the clouds circling all around us, and with nothing but greyness to either side it seemed like we were the center of the whole world.
"Here we are," said Petrel as he took the sail down. "Come on then."
He handed me a small bucket of some sort.
"Fill that with tar," he ordered.
I filled the bucket up, and he placed a special lid on top. There was some kind of wick protruding from the top, which he lit. As the tar slowly burned, we held the balloon open above it. We waited, and the balloon slowly expanded out and began to take a rounded shape. I could feel it starting to pull away from me, and when Petrel gave the nod we both let go.
The balloon rose upwards, carrying its small burning heart high up into the sky. I stood and watched it climb ever higher. It might have been a mile up, I couldn't tell, when it suddenly erupted in bright flame. The fire must have spread to the outer cloth which we'd coated in tar. The whole thing glowed bright orange against the grey skies, a stack of smoke spreading out wide into the storm.
The beast woke. I didn't just hear it, I felt it. A giant roar of thunder bellowed through the air around us. The air became an icy white, with vague outlines forming amongst the wind. And there, high in the sky in front of me, I saw it. The Eye of the Storm. The giant floating eye, made of nothing but raindrops and ice, opened wide and looked right at us. I said nothing, for there was nothing I could say, and the beast said nothing in return. But I felt that monstrous Eye look right into my heart.
I thought I was surely done for, yet it did not take me. It seemed intrigued by us, and I imagined perhaps it understood. The Eye tilted as it studied us, while I felt the wind beat ever harder. Then, with a sudden movement, as if it had heard something, the great Eye quickly turned and gazed to the south-west, back towards land.
It let out a mighty roar again, and rose up into the sky. As it moved I felt an enormous gust of air, and I was flung overboard into the cold sea. The world around me turned dark, but I felt a hand reach for mine. The aeromancer pulled me up, and I found my way back into the boat again.
"It is angry," he said, "but it understands. It rises to claim its territory once more."
The wind which before had circled, now changed and drove us hard in one straight direction. Petrel raised the sail again and the wind caught it immediately. We were pushed back towards land now, dragged hard and fast by the Nor'easter. It paid no attention to us any more, for its gaze was fixed only on one thing; the intruder on the land it claimed as its own.
The wind was coming.
With the gale at our backs, we made it to shore in half the time it had taken to venture outwards. The weather was fierce the whole way; I huddled under blankets and tried to dry myself the best I could. A distant sliver of blue sky sat on the horizon, but shrank with each mile we covered.
I said nothing to Petrel; I was too scared to even open my mouth for fear the Nor'easter would take me. I suppose I needn't have worried; the wind was no longer interested in our little boat. I kept trying to tell myself that but it helped none.
We hit the beach and clambered out of the skiff. The Nor'easter was no longer running straight, but was circling the coast, building strength.
"Come!" cried Petrel. "We must shelter!"
"There's nothing here!" I shouted back over the noise of the wind. The beach was empty with nothing but open sea to one side, and the eastern hills to the other. It would be a mile to the nearest farm, the town being the same again.
We scrambled up the hillside, my eyes checking for anything that could provide shelter. As we reached the top I saw a lone wooden structure--Wenwright's mill.
"The mill!" I shouted. "Come on!"
Petrel was slower than me, and I held open the door at the base of the windmill, and waited as he caught up with me. The weathervane on the mill span in every direction as the Nor'easter circled with increasing ferocity.
I closed the door after him, but there was no bar to draw. The mill wasn't designed for living in; there was no sealant anywhere, and every crack between the planks let the air through. Petrel saw my expression as I scanned the room.
"Fear not!" he said. "We are out of the wind, that is all we need. The Nor'easter will pay us no attention. It has far more pressing matters."
He stood at a crack in the timber, watching the skies outside. He didn't seem scared at all; he just watched it with excited eyes, like a child watching a play. I had frozen motionless next to the giant millstone that filled the room, but he beckoned me over to watch with him.
From up here on the hilltop, you could actually see it, not a solid shape but an outline formed only from the glint of the rain it carried with it. A giant trail, ten miles long, stretching back out to sea. The Nor'easter rushed across the farms toward the town, while from the other side a bolt of lightning lit up the sky. From the west, the new wind was coming to meet it head on.
The two giant beasts clashed above the town. The two winds collided with an almighty peal of thunder, and then span and circled around each other. They danced and weaved in the sky like flocking birds, and pushed each other eastwards, across the farmlands. You could see them only as faint glimpses; streaks of white that cut across the sky, causing eddies in the clouds with every turn. With each bite they made at each other, bolts of lightning would cut through the clouds and a crack of thunder would follow.
As the winds spun, a tornado formed below them. The towering grey funnel touched down on Danson's farm, and ripped his barn into a thousand shreds.
It kept moving, never sticking to one direction, but bearing eastwards towards the very hilltops we stood on. As the fighting beasts approached us, the wooden frame of the windmill started to shake back and forth.
I grabbed the aeromancer by the arm. "Come on!" I shouted. I had to almost pull him away, but he followed. There was nowhere else to go, but I grabbed onto the tall wooden shaft of the mill and held on for dear life.
The windmill was old, and weak. The timbers creaked as the blades span faster than they ever had before, and I struggled to hold onto the shaft as it turned.
The old wooden structure could not take the force. The winds ripped the timbers clean off the frame and sent them flying into the storm. Pieces of wood flew everywhere, and I caught a good cut right across my cheek from a flying splinter.
We were left exposed. There was nowhere to run, no other buildings to hide in high up on these hills. The force of the gale was overwhelming. High overhead, the two beasts continued their fight, paying no attention to the destruction far below.
The millstone and its shaft were all that remained of the mill, and I held tight onto what remained of the wooden shaft. I shouted to Petrel but he couldn't hear me over the roars of the two giants. I tried to motion to him to join me, but he wasn't paying any attention. His gaze was fixed on the battle that raged above.
A huge gust swept through, and I was lifted clean off my feet. I held onto the pole to stop myself being carried away. I shouted out again to the aeromancer, but he was no longer there.
I thought him dead, but then I spied him. The tornado had lifted him up into the sky. But as he was carried off, out of his cloak he pulled a strange cloth device; the one I had seen him with when we set off our voyage. He unfolded it above his head and it caught the wind like a sail.
Away he sailed, riding the breeze like a gull rising on the updraft from a cliff face. I saw a strange smile on his face, as if nothing in the world could bother him. The winds took him far away into the skies, a blue dot against a grey canvas.
The gust dropped, and I found my footing again. The tornado had turned and moved back to the farmlands. I watched the two beasts battle. I could no longer tell which was which, but it seemed one was emerging as the victor. The tornado was unwinding, and the wind was prevailing in a constant direction now from out to sea.
A giant roar filled the sky, so loud I could feel myself pushed by the sound alone. The Nor'easter had won, I was sure of it. The sky thundered and lightning ripped across the sky with every roar. I stood on the hill and watched as the lone remaining wind circled the town. I felt an almost strange sense of victory, as if the battle had been my own.
My pride was short lived, however. The wind would be hungry after its battle. And here I was, exposed out on this empty hilltop. I looked around frantically for any kind of building, anything I could shelter inside, but there was nothing.
Then I realized where I needed to be; the tar kilns that lay not a quarter mile from here. I wasted no time and dashed through the pine trees towards the clearing where they sat.
The kilns were sunk into the ground, with only a small doorway leading to the tiny underground chamber where the barrel sat, catching the dripping resin from above. They were only intended to hold a barrel, not a person, but I made do. I heaved the half-full barrel out of the chamber, spilling its contents everwhere, and squeezed myself into the tiny gap instead. There was a small rope handle used to pull the door; I tied the loop around my foot and sat there in the darkness.
The smell of pine tar was overwhelming, and the floor and walls were sticky with years of tar that had been spilt there. I sat and waited while the noise continued outside. The battle may have been over, but the Nor'easter circled above for hours, reclaiming its territory once more. It would no doubt be looking for an easy meal, and I hoped it would find a sheep out on the farmlands, but I wasn't going to risk it finding me instead.
I emerged hours later once the wind finally dropped, my clothes and skin dripping with the sticky tar, leaves and mud stuck everywhere. I can't imagine what I must have looked like, but I was too tired to care.
And so I began the long walk back to town.
It's 6 months after as I write this. The winter was hard, the Nor'easter fed well and took more than its fair share of the herds. That's the price you pay for waking it early; a risk we had to accept I suppose.
The Nor'easter slept early. It's spring now. They're talking about rowing a boat out to sea this month, sayin' there might be time enough now to go fishing before the Summer Westerlies arrives. Old Carson asked me to go with them, saying I was an old hand now, but I'll never set foot in a boat again.
The battle wrecked the eastern farms. Most of the town is intact, as the battle happened to the east, though Ned Mitchell died; a piece of flying timber caught him a good blow to the head.
I never found out what happened to Petrel. I like to think he floated away on his thingamabob and found his way down somewhere. Or maybe the wind got him, and he finally found his place in the great cycle.
Old Fessler used to say he'd teach me about the great cycle too, one day, though he never did. It had always puzzled me that he never complained much about his leg, never blamed the storms for hurting him. Perhaps he knew his place in things.
We had no more trouble with the new wind anyway. Petrel was right, the balance needed to be restored. Of course, some folks still get all panicked each time some small zephyr flies through town, but it don't worry me. Sometimes you just gotta go where the wind blows you.
-
Disassembling Jak & Daxter January 12th, 2017
Disclaimer
I don't work at Naughty Dog, and I don't have any secret knowledge of Jak & Daxter, except what I figured out myself from the disc. So a lot of this may well be wrong. Take a pinch of salt with it.
The massive world of Jak & Daxter
I've always had a fascination with Jak & Daxter ever since it came out, way back in 2001 on the PlayStation 2. It was one of the first 3D games I'd actually seen run at 60Hz. I was used to PC games like Quake which were software rendered, or games like Mario 64 which I played (and completed!) on UltraHLE at a woefully poor framerate. But Jak & Daxter, hereafter referred to as J&D, blew me away.
Here was a game running at a silky-smooth 60Hz, never missing a beat, and somehow managing to draw more polygons than any other game out there. A game where you could see and explore a vast world with no boundaries. No load screens, no pauses, no LOD pops. It all just fit together perfectly. I had to know more.
The J&D engine may possibly be one of the greatest engines ever made. Of course, because it's not open source, it doesn't get the recognition that more famous engines like Quake get. There's not much information out there about it, but there's a few snippets here and there. The most important for you to read would be Stephen White's 2003 GDC talk, "The Technology Of Jak & Daxter", which I can't find a link to any more but I've mirrored here:
Link
The Technology Of Jak & Daxter, Stephen White (GDC 2003)
The audio contains some additional Q&A not in the slides.
There's a lot to talk about, but today I'm going to ignore all the cool graphics tech and such, because I want to focus on the most amazing element: GOAL
GOAL, standing for "Game Oriented Assembly Lisp", is the programming language J&D is written in. All of it. I want to really nail this point home here -- some people think it's some kind of bytecoded scripting language. It isn't. GOAL is a fully natively-compiled general purpose programming language, and the whole game is written in it.
It's a hell of a thing, when you think about it. To create your own programming language, from scratch, and then write the entire game engine in it. I don't know of any other games out there that do that.
The only part of the game not written in GOAL is the loader/linker, which is written in C++. This is the equivalent of their DLL loader; it's just a simple stub program to load the rest. And this is what this article will be picking apart, as it forms the gateway to everything else.
Because GOAL has its origins in Lisp, one of it's hallmarks is that symbols are considered a first-class datatype. There is no offline linker, everything is dynamically linked. Therefore the symbol table must be present in the runtime data. What this means is that if we can understand the data format, we can get a complete symbolic disassembly of the whole game.
If you want to follow along at home, you'll need a copy of the PS2 J&D disc or ISO, and the source code I've posted at the end here.
The loader
Let's start at the loader. This is the first thing that loads, and is just a regular PS2 ELF compiled with gcc. For whatever reason (lack of attention possibly), Naughty Dog forgot to strip the ELF symbols from this file, which means we can open it up in any MIPS disassembler and follow its logic through.
The function of the loader is simple. It sits waiting, and when new data arrives from wherever, it allocates space on the heap and copies the data there. It then relocates the pointers to the new address, and patches up any references to the global symbol table. Once this is done the data is ready to go. That's basically it; there's no VM or interpreter here.
The loader generally tracks 3 different memory heaps -- the common heap, and two level heaps. The game has two levels loaded at any one time, each getting their own self-contained heap (this is what allows you to seamlessly walk from one to another). The common heap contains the core engine code and data. The loader just uses a simple bump allocator to throw new data on the end. Once the level is finished with, it just throws out the entire heap and starts again.
So where does the loader get its data from? First we need to examine the file formats used here. If you look on the disc, the main files used here are called "CGO" and "DGO". There's no actual difference between them, I presume the names just reflect the usage (code/data?). It tends to be that CGO files are loaded into the common heap, and DGO files are loaded into the level heaps. However, don't be confused by the names -- just because they imply code and data separately, the contents are in fact mixed and can contain both code and data interchangeably. In fact, as we'll see later, GOAL doesn't really distinguish the two concepts.
The DGO format is real simple. There's a simple header, and then it's just a bunch of binary files concatenated together. It's closer to a ZIP archive than it is to something like ELF. The DGO is just a way of delivering binary blobs one at a time.
In the retail version, the IOP (the PS2s input/output processor) delivers the DGO file as-is into the loader when requested. In the development builds however, they also listen on a network port for incoming binaries. This is how their development process works -- they can compile new source files on their development machine and stream them straight into the PS2 while it's running. The target PS2 doesn't even know where the files came from, it just loads them in like any other.
It's not really fair to call this "hotloading", it's really just "loading", as updating the game with new code/data is no different than loading it in the first place. This is made possible by the dynamic symbol table in the linker, which we'll look at later in the top-level section discussion.
So, we can easily write a little program to pop open a DGO and extract the files within. They don't have an official extension but I'll refer to them as ".go.bin", assuming they were compiled from a ".go" originally. But what do these binaries exactly contain?
A .go.bin is basically the equivalent of a .OBJ file from a normal C++ compiler. It contains 3 sections, as well as relocation tables to patch them with:
- the
top-levelsegment - the
mainsegment - the
debugsegment
These are loaded in-place by the loader, which makes loading very efficient. The loader does not have to actually parse the data or even know what it is. As far as it's concerned, we're just loading 3 big chunks of data in and then patching them up afterwards.
The top-level segment
The
top-levelsegment contains everything at global scope from the source file. Because this only executes once, the loader loads it, runs it, and then throws it straight away. Its main purpose is to register functions into the global symbol table. Because functions are first-class objects in GOAL (like most other things), they're just function pointers. So registering a function is simply a matter of storing a pointer to it in the symbol table.This means that every single function call in J&D goes through a pointer (i.e. is a virtual function). People always used to tell me this was bad on the PS2 as, oh I don't know, DCACHE misses or something. Well seeing as J&D is one of the best performing games on the system (or any system), it doesn't seem to have done them any harm.
Here's an example excerpt of a
top-levelsegment:; eye ;================================================================== .segment top-level-segment ;================================================================== ;------------------------------------------------------------------ .type function goal-entry: lui v1, L35 or v1, v1, L35 sw v1, *eye-work*(s7) lui v1, L26 or v1, v1, L26 sw v1, render-eyes(s7) lui v1, L12 or v1, v1, L12 sw v1, update-eyes(s7) lui v1, L11 or v1, v1, L11 sw v1, get-eye-block(s7) lui v1, L10 or v1, v1, L10 sw v1, convert-eye-data(s7) lui v1, L1 or v0, v1, L1 sw v0, merc-eye-anim(s7) jr ra daddu sp, sp, r0
In this example, what we're doing is loading the address of a function (e.g.
render-eyes) and storing it at an offset into the global symbol table (register s7). Note that GOAL symbol names can happily contain dashes, asterisks, and other Lispisms. GOAL keeps a pointer to the symbol table in register S7 at all times, and all global variables/functions are always referenced via this.So when this file is loaded into the system, it simply registers the existence of 6 named global objects, and then returns.
I'll give you a brief example of how something like this might be generated. Imagine the following C function:
int my_function(int x, int y) { return x+y; }
In GOAL, you might write this in a more Lispy syntax: (I guessed at the syntax from snippets I've seen online, don't peek too closely)
(defun my_function ((x int) (y int)) (return (+ x y)))
Looks similar on first inspection, but the key difference is
defun(short in Lisp for "define function"). This is a macro. We're not actually defining the function ourselves here, what we're doing is passing our code into the "define function" macro. The macro will run at compile time and rewrite our code, and we'll end up with something like this:// top-level segment: symbols["my_function"] = &L1; // assign fn ptr to symbol // main segment: int L1(int x, int y) { return x+y; }
So effectively, the top-level segment is just doing at runtime the work that most compilers do at compile time. Instead of writing symbol tables into an ELF file, we set it up ourselves upon loading.
The main segment
The main segment contains the real work. Because this is just a binary chunk, it could contain anything. Typically it tends to be either a set of function bodies, or some data structures containing art data. Either way, the top-level segment will refer to these objects and patch them into the running system.
For me, this is one of the most beautiful aspects of the GOAL system; the mixing of code and data. The system just doesn't care. There's no code in GOAL to, for example, parse an XML file into a structure. It's just not needed. If you want to fill in data, you just embed that data right into the binary. I wrote about this way back in my old article, The Joy Of INCBIN. GOAL takes this idea to its extreme. Textures, models, etc, are all processed by offline tools which write out .go files, which the compiler then just packages up like any other data set.
As far as GOAL is concerned, a function body is just an object like any other, no different from an array or a struct. Each allocated GOAL object has a 4-byte header in front of it which contains a pointer to its type, used for both debugging and runtime polymorphism. Note that I didn't say "type debugging information", I said "type". This is because in GOAL, a type is itself an object as well. You can even create new types at runtime if you like.
The debug segment
Lastly we have the debug segment. The game doesn't normally load this in a retail build, it just skips over it. During development however, it contains assorted extra information used for debugging. In a regular ELF binary, you might expect to find encoded DWARF data or some other format that described all the symbols and types within. Well that's not how GOAL works.
GOAL can't list the symbols within the file because there aren't any. Remember, we patched the symbols into the system ourselves in the top-level segment? The code itself decides what to assign to what symbol at runtime, not compile time.
It also can't list the type information, because types are a purely runtime construct too. That's not to say that this is a dynamically-typed language like Lisp or Python, because it isn't. The compiler emits static native code assuming the layout of types, just like a C++ compiler would. The key to understanding GOAL is to realize that types are just something the runtime lets you create at will, and the compiler is just making use of that facility in advance.
So if there's no type info here and no symbol table here, what is here? Well, it tends to just contain a bunch of functions (probably compiler-generated) that know how to print out and inspect the contents of the types the compiler made.
GOAL never had a source-line debugger, as far as I know, although there's no reason it couldn't given some effort to write one. (edit: wrong, see here) So it seems like the main mechanism Naughty Dog used to debug with was to pull up a console and enter commands to print and inspect various data themselves. (Remember, the system can compile a new single-line function and download it straight into the loader at any time! This gives you a free debug console.)
That's not actually as bad as it sounds; bear in mind this is a fully live-editable system, so if there's a function you want to investigate you can easily just patch in a printf while the game's running and mess around with it.
Getting a disassembly
So that's pretty much all there is to loading compiled GO files. You can disassemble the ELF loader to figure out the exact file format, and what with having the ELF symbols for the loader available, it's not that hard to replicate the function of the loader ourselves.
So I did.
Below is a small program that loads DGOs, disassembles them back into MIPS assembly, and writes it all out. The assembly format isn't quite standard, as there's a few things the
.go.binformat needs that a regular assembler wouldn't provide. In particular it would need to understand how to write the symbol names used into the relocation table, and how to prefix each stored object with a pointer to its type.I suspect most people won't be that interested to actually pick through it all themselves, but still, here it is. Let me know if you find any of it interesting!
- https://github.com/rmitton/goaldis - My command-line disassembler
- the
-
Converging Towards Disneyland December 19th, 2016
Warning
Contains (very minor) spoilers for The Witness.
Jonathan Blow's 2016 game The Witness received high praise from most reviewers. Personally, I loved the island and the environmental puzzles, but I hated all the stupid little NP-hard slidey-line puzzles. I'm not here to moan about that today though. Let's talk about layout.
The island itself is an absolute joy to explore. No corner of it is wasted, nothing is filler. Everywhere you look you'll find some new little piece of entertainment. It's designed for you to be able to wander at will and always find new things.
Yet as I uncovered the whole island, something about it struck me as familiar. A feeling I'd seen something like this before. It wasn't until I found the in-game map that I realized what it was.
Imagine you start from the cove at the bottom. You disembark the boat, and venture forth to the buildings you see. The island has a town in the middle which forms the main hub of the island. North from there leads to the castle centerpiece, or you can wander out to any of the puzzle areas that fill up the rest of the island. Surrounding the island is a transport system, the boat, to let you move around quickly. The game culminates within the giant mountain to the south-east.
Now the game itself doesn't actually start you via that route -- instead you start in the bottom-left, where you're encouraged (but not strictly required) to explore some of the puzzle regions there first. This is because it wants to teach you about the game world one step at a time. However, once you advance past a certain point it becomes clear that the town area is the part you'll keep coming back to.
Here's an (official) labeled map of the different areas in the island. Note that the town is labeled as "hub":
Seeing it yet? OK I'll admit perhaps I'm stretching a little here, but... it's Disneyland, right? Not literally of course, but I can't help notice the design similarities. Compare against this historical map of the park:
It's the same design. Disneyland has a monorail around the perimeter; the Witness has a boat. Disneyland has a town hub and castle in the center, so does the Witness. Space Mountain became the mountain, and sits in the same corner of the island as its real-life counterpart. And like the real-life one, it's hollow on the inside. A visitor wanders around the park's attractions, but always keeps coming back to Main Street where the shops are.
In The Witness, if you take the boat all the way around the island, you'll eventually be taken on a little ride through these sunken shipwreck ruins. Now admittedly there's no little people singing "It's A Small World" (thank god), but I definitely got the same vibes of going on a little boat ride through an indoor exhibit. It's even in the same top-right area of the map.
The island of The Witness definitely isn't Disneyland, and only slim elements match up, but in terms of design and layout there's this nagging feeling of subconscious echoes.
Zelda, Phillips CD-i, 1993
OK, maybe it's just my imagination, I dunno. But I'm not the only one to notice common themes between The Witness's island and other designed experiences. @tydaspy pointed out the similarities in style with the world map from the 1993 Zelda game "The Wand Of Gamelon" released on the Phillips CD-i.
I've been trying to put my finger on exactly why we see these similarities. I don't think it's intentional. I'm not suggesting that Jon Blow started from Disneyland as his base to work from. Instead, I believe we are seeing an example of convergent evolution.
These games (and Disneyland) have some of the same design constraints. They want a world with as many different things in as possible. They want the smallest space, sometimes because of limited real-estate or limited construction resources, but also to minimize the amount of walking the guest has to do.
